🟧 Introduction
The ability to accurately measure and monitor tank quality in real time has become a game-changer for refineries and chemical plants worldwide. While traditional manual sampling and lab analysis methods have been reliable for decades, they come with significant delays, labor-intensive processes, and operational inefficiencies. Today, advancements in online analyzers and model-based quality estimation systems are transforming the industry, enabling refineries to optimize operations, reduce costs, and enhance real-time decision-making.
This newsletter explores key findings from a comprehensive study by Dr. Suresh S. Agrawal of Offsite Management Systems LLC, highlighting innovative techniques in tank quality measurement and their economic impact.
🟧 The Challenge: Inefficiencies in Traditional Tank Quality Analysis
Tank farms serve as critical storage units for feedstocks, intermediates, and final products in refineries. Knowing the exact contents of these tanks—both in terms of quantity and quality—is essential for operational efficiency. While online automatic tank-gauging systems provide real-time inventory data, obtaining quality information in real time remains a challenge.
Traditional methods for tank quality measurement rely on three primary approaches:
1. Manual Sampling & Lab Analysis
-
Operators draw samples at scheduled intervals and send them for lab analysis.
-
Customizable and flexible but time-consuming and manpower-intensive.
-
Results have inherent delays, leading to inefficiencies in real-time process control.
2. Online Analyzers
-
Installed at process streams or tank outlets, providing quicker data.
-
Offer real-time monitoring but require high capital investment and frequent maintenance.
-
Limited measurement scope requires multiple analyzers for comprehensive coverage.
3. Model-Based Quality Estimation
-
A software-driven approach using advanced algorithms to predict tank qualities.
-
Reduces reliance on direct sampling and online analyzers.
-
Leverages historical and real-time data from tank inlets for accurate estimations.
While each method has its merits, an integrated approach that combines the best of these methods is essential for efficient refinery operations.
🟧 The Solution: Real-Time Tank Quality Tracking Systems (TQTS)
Online Analyzers: Benefits and Drawbacks
Online analyzers provide a significant advantage over manual sampling by offering near real-time quality data. However, they also come with limitations:
-
High initial costs: Expensive to install and maintain.
-
Limited scope: May require multiple analyzers for different quality parameters.
-
Restricted availability: Typically active only during blending operations.
Despite these challenges, online analyzers significantly reduce workforce needs and integrate seamlessly with advanced blend control systems, optimizing operations and minimizing product giveaways.
Model-Based Tank Quality Estimation (TQTS)
Figure 1: Model-Based Tank Quality Estimation (TQTS)
The Tank Quality Tracking System (TQTS) represents a paradigm shift in refinery optimization. Unlike discrete analyzers, TQTS uses advanced mathematical models to estimate tank qualities continuously. Key benefits include:
-
Continuous quality estimation across all tanks, improving process control.
-
Reduction in lab analysis costs by making real-time data available online.
-
Integration with upstream processes to enable proactive control adjustments.
-
Minimized human intervention and sampling errors, improving operational accuracy.
A case study at Singapore Refining Company (SRC) demonstrated that implementing TQTS reduced lab analyses by 40% and improved operational efficiency, leading to annual savings of approximately $482,000. Additionally, the system achieved over 90% accuracy in predicting tank qualities compared to lab analyses, demonstrating significant economic benefits.
Case Study: Real-Time Quality Tracking in Blending Operations
Figures 2 and 3 illustrate the implementation of a real-time tank quality tracking system for two different blending configurations:
-
Figure 2: Open-Loop Run-Down Diesel Blending – Involves blending components as they flow to the storage tank, requiring continuous quality tracking.
-
Figure 3: Closed-Loop Online Gasoline Blending – Uses real-time feedback from tank quality data to dynamically adjust blending ratios, optimizing final product specifications.
Figure 2: Open-Loop Run-Down Diesel Blending
Figure 3: Closed-Loop Online Gasoline Blending
By leveraging TQTS in these configurations, refiners can ensure near real-time availability of tank quality data for planning, offline optimization, and online control systems.
🟧 The Economic Case: Cost Savings & ROI
The financial implications of implementing TQTS are substantial.
Refineries that integrate model-based quality estimation can expect significant cost reductions:
-
Reduction in Lab Costs – Cutting unnecessary lab analyses saves hundreds of thousands of dollars annually.
-
Optimized Blend Control – Real-time tank quality data ensures minimal product giveaways and improved profitability.
-
Minimized Reblends & Downtime – Continuous monitoring enables proactive adjustments, preventing costly reblending operations.
A refinery investing in TQTS can typically expect a return on investment (ROI) within 4-6 months, depending on plant size and operational complexity.
🟧 Industry Adoption & Future Trends
As refineries seek to enhance efficiency and profitability, digital transformation and automation are becoming industry standards.
Future advancements in tank quality measurement are expected to include:
1. AI-Driven Predictive Analytics
-
AI and machine learning will enhance predictive accuracy in tank quality estimation.
-
Adaptive models will continuously improve through data-driven insights.
2. Blockchain Integration for Quality Tracking
-
Blockchain can provide a secure and transparent record of quality parameters.
-
Ensures authenticity and traceability of product quality throughout the supply chain.
3. Cloud-Based Monitoring and Centralized Data Management
-
Cloud platforms will enable centralized monitoring of multiple refinery locations.
-
Improves accessibility and facilitates real-time collaboration between teams.
🟧 Conclusion: The Future of Tank Quality Measurement
Refineries that embrace real-time quality measurement solutions can expect significant financial and operational benefits. By shifting from traditional manual sampling to TQTS-driven predictive models, organizations can enhance efficiency, reduce costs, and stay competitive in a rapidly evolving industry.
Investing in Tank Quality Tracking Systems is no longer an option—it is a necessity for refineries aiming to thrive in the digital age. Those who adopt these advanced solutions will position themselves as industry leaders, leveraging real-time insights to drive profitability and operational excellence.
